Caddx Turbo Micro SDR2 Plus Freestyle Version FPV Camera



Availability: 3 in stock Categories: , ,


The Cadex Turbo Micro SDR2 Plus comes in the Freestyle version and the Hotfire color scheme. It comes with the high-quality 1/2.8″ SONY Exmor-R STARVIS image sensor coupled with the Turbo Eye Lens with F1.8 focal length and sensitivity of up to 0.0001 lux plus 1200TVL resolution for a really impressive package.


With the OSD menu, you can switch between PAL and NTSC video standards, or between 4:3 and 16:9 video formats. It also has Super WDR and 3 DNR plus the ability to change between auto, color and black and white modes it is a very versatile camera. It can be powered from 2S to 10S lipo batteries (5 to 40V DC).


The Cadex Turbo Micro SDR2 Plus Freestyle version has extreme image resolution for quality images. Get one now and view the difference.


• 1/2.8″ SONY Exmor-R STARVIS sensor
• 1200TVL
[email protected] (Starlight)
• Turbo Eye lens
• Super WDR
• 3 DNR
• NTSC and PAL switchable
• 16:9 and 4:3 switchable
• Input power 5~40V DC

Additional information


Image Sensor: 1/2.8" SONY Exmor-R STARVIS sensor
Horizontal resolution: 1200TVL
Television system: NTSC and PAL (can be changed using OSD)
Image: 16:9 and 4:3 (can be changed using OSD)
WDR: Super WDR (Double Scan)
Illumination: [email protected] (Starlight)
Lens: Turbo Eye
Synchronize: Internal
Electronic shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
Signal to noise ratio: > 60dB (AGC OFF)
Video output: CVBS
Camera OSD: Advance menu
Language: ENG /France / RUS / SPA / PU /Korea / CHN / JAPAN
Day/Night: Auto / Color / Black & White / EXT
Dimensions: 19x19x19 mm
Wide power input: DC 5-40V
Operating temperature: -20°C~+ 60°C
Working humidity: 20%~80%
Weight: 5.5g

In The Box

1 x camera
1 x aluminum bracket
1 x 5D-OSD menu board
1 x 4pin FPV silicone cable A (2-pin connector to OSD board and 3-pin connector for FPV)
1 x FPV silicone cable B (2 pin ports on both sides)
1 x hex wrench
1 x screw set
