Description

Flight Parameters

• Total Weight (without batteries): 14.0 kg
• Max Takeoff Weight: 55.0 kg
• Max Operating Speed: 35 kph
• Max Flight Speed: 65 kph
• Hover Time: 65 min (at 26.3 kg TO weight) – 14 min (at 48.0 kg TO weight)

Propulsion System

• Motor KV: 100 rpm/V
• Foldable Propeller: 76.2×22.9 cm
• Configuration: Octocopter
• Operating Voltage 12s
• Battery: 2 x 16000 mAh 12S (44.4V) LiPo Batteries – 4.7 kg/battery

Aircraft Frame

• Wheelbase: 212 cm
• Material: Carbon Fiber, Aluminum, Plastic
• Dimensions: 206x206x64 cm (arms unfolded, no propellers) – 112x112x64 cm (arms folded, no propellers)

Spray System

• Standard Payload: 21.5 kg, 21.5 L
• Sprayer Configuration: 8 nozzles underneath rotors
• Nozzle: Nozzle body compatible with any Teejet spray tip
• Flow Rate: 0.14 – 1.13 Gal/min
• Spray Width: 4.5 – 6.1 meters

Flight Control

• Flight Modes: Fully autonomous (no RC), position hold manual (with RC)
• Operating Frequencies: 902 – 928 MHz, 2.4 GHz
• Ground Station Control Software: Hylio Agrosol
• Max Transmission Range: >15 kilometers (unobstructed)
